Lake People G100 FE (Final Edition) Headphone Amplifier

Lake People G100 FE (Final Edition) Headphone Amplifier

Lake People G100 FE (Final Edition) Headphone Amplifier

7 Reviews

Reference:

1823

Condition:

New

Read moreShow less

€439.00 (tax incl.)

Available for immediate shipping.

Quantity

Brand:

Violectric

Add to wishlist(1)

Description

PHONE AMP G100 can be regarded as the ancestor of the HiFi / HiEnd units from von Lake People and Violectric.
It was the first item from Lake People which was widely used by professional and private customers. Professionals praised the indestructible stainless steel construction while private users loved the exceptional sound quality.

PHONE-AMP G100 FE includes all major construction details which are still important:

- transistorized amplifiers for unmatched transmission quality
- smooth performing RK 27 Potentiometer for volume control
- oversized power supply with toroidal transformer

Also, PHONE-AMP G100 defined for the first time or technical guidelines which
are still unique in their combination:

LOWEST NOISE
because of low internal gain.
Therefore the self-generated noise from the amplifier is not audible.

HIGHEST OUTPUT VOLTAGE
through 60 Volt internal operating voltage.
Over 90 % of all headphone amplifiers in the market offer not half that voltage !!
Therefore best suited for high impedance headphones.

HIGHEST OUTPUT POWER
because of powerful amplifiers able to deliver much more current a headphone needs.
Therefore best suited for low impedance headphones and even magnetostatic cans !!

HIGH DAMPING FACTOR
through lowest output impedance.
Therefore best suited for full control even over critical headphones with
the guarantee to have flatest possible response.

By the way:
the launching of Violectric was due to the marketing success of PHONE-AMP G100 !

All this is not too long ago, nevertheless a reason for us to offer again
PHONE-AMP G100 FE as Final Edition in a limited Edition for a very special price !!

The Features:
- balanced inputs via gold plated XLR connectors
- unbalanced inputs with priority via gold plated RCA connectors
- PRE-GAIN: gain adaption in five steps
- no-SMD and channel separated circuitry for minimized crosstalk
- discrete amplifier design with 4 transistors per channel (V100 Technology !)
- NF transmission band exceeds 150 kHz (-3 dB)
- High-Grade Potentiometer Alps RK 27 with optimized channel balance and lowest cross talk
- toroidal transformer, large smoothing capacitors
- outputs with relay controlled switch-on delay
- ultra compact stainless steel case

Technical Data

	Balanced inputs:	2 x XLR (L / R), gold plated
	Unbalanced inputs:	2 x Cinch (L / R), gold plated with priority
	Impedance:	10 kohms
	Amplifier Channels:	2 (Stereo)
	Nom. input level:	+ 6 dBu
	Amplifier Gain:	+8 dB
	... with PRE-GAIN:	-4 / +2 / +8 / +14 / +20 dB
	Frequency range:	0 Hz ... 150 kHz (-3 dB)
	Slew Rate:	> 8V / usec
	Dynamic range:	> 129 dB (A-wtd)
	Noise:	< -101 dBu (A-wtd)
	THD+N:	< -100 dB @ 10V in 100 Ohms (1W) < -100 dB @ 18V in 600 Ohms (5W)
	Crosstalk:	< -110 / -95 dB (@ 1 / 15 kHz)
	Max. output level:	> 18.9 Veff in 600 ohms = 600 mW
		> 16.5 Veff in 300 ohms = 900 mW
		> 13.2 Veff in 100 ohms = 1750 mW
		> 9.2 Veff in 50 ohms = 1700 mW
		> 6.2 Veff in 32 ohms = 1200 mW
		> 3.5 Veff in 16 ohms = 750 mW
	Outputs:	2 x 1/4" phone jacks
	Power supply:	230 / 115 V AC 10 VA
	Dimensions:	129 x 42 x 170 mm (W x H x D)
	Case Material:	Stainless Steel

Introduction to Lake People

Established in 1986, we have since become your partner for professional audio electronics. Following our motto “tools - not toys”, we achieved highest reputation during the past years amongst our customers. These are private studios, broadcasters and TV companies. Also airports, congress and exhibition centres count on the reliability of our products made in Germany. This all began under the roof of Rosgartenstrasse 13 in the city of Konstanz. Here, three young guys started with the development and manufacture of limiters and noise gates but not too successfully in the beginning. The commercial survival on a very low level was made possible by the production of headphone amplifiers. From 1989 on, the production range was extended to level matching and balancing amplifiers such successfully, that it came essential to move to larger premises.

Since 1991, the new address read: Haidelmoosweg 52. Due to the developement of the first german 20-bit A/D and D/A converters in the beginning nineties, the name Lake People resounded throughout the land. Suddenly, the company was regarded as a high-tech brand, with a highly positive effect on its public reputation. The growing know-how led to many new products in the analog and digital domain during the following years. Although some projects turned out to be flops, most devices met the customers' requirements, with the effect of continuous growth of the company. By the end of the nineties the 140 m² of Haidelmoosweg 52 went cramping.
Again, a move to new premises came necessary. As it was obvious that rental facilities would not meet the demands, we decided to put up our own building. The company site was constructed in 2000 in a new industrial park in Konstanz, Turmstrasse 7a, just a hundred metres from the lake. Also in 2000, Lake People was transformed into a Ltd. company.

Read moreShow less

Product Details

Reference 1823

Designer

Introduction to Violectric

... is a trademark and product line of Lake People electronic GmbH. Lake People electronic GmbH develops, manufactures and distributes products in the professional range, for broadcast, television, airports, exhibition halls, festival venues, theatres, large-scale installations, private studios and more. In the private sector as well, Lake People products become increasingly popular due to their outstanding quality.
The Violectric trademark and product line is specially intended to supply the Hi-Fi and High-End market with its specific requirements.

Who develops Violectric equipment?

Violectric devices are exclusively developed in Germany by the engineers of Lake People electronic GmbH. In doing so, the team of developers can draw on twenty years of experience and countless products for the pro-audio domain.

Who manufactures Violectric equipment?

Violectric devices are exclusively manufactured in Germany by Lake People electronic GmbH or contractors in the company's vicinity. Lake People - and by association Violectric - put high emphasis on domestic manufacturing. As well, all component suppliers are chosen in order achieve the main part of added value inland.

Introduction to Lake People

Established in 1986, we have since become your partner for professional audio electronics. Following our motto “tools - not toys”, we achieved highest reputation during the past years amongst our customers. These are private studios, broadcasters and TV companies. Also airports, congress and exhibition centres count on the reliability of our products made in Germany. This all began under the roof of Rosgartenstrasse 13 in the city of Konstanz. Here, three young guys started with the development and manufacture of limiters and noise gates but not too successfully in the beginning. The commercial survival on a very low level was made possible by the production of headphone amplifiers. From 1989 on, the production range was extended to level matching and balancing amplifiers such successfully, that it came essential to move to larger premises.

Since 1991, the new address read: Haidelmoosweg 52. Due to the developement of the first german 20-bit A/D and D/A converters in the beginning nineties, the name Lake People resounded throughout the land. Suddenly, the company was regarded as a high-tech brand, with a highly positive effect on its public reputation. The growing know-how led to many new products in the analog and digital domain during the following years. Although some projects turned out to be flops, most devices met the customers' requirements, with the effect of continuous growth of the company. By the end of the nineties the 140 m² of Haidelmoosweg 52 went cramping.
Again, a move to new premises came necessary. As it was obvious that rental facilities would not meet the demands, we decided to put up our own building. The company site was constructed in 2000 in a new industrial park in Konstanz, Turmstrasse 7a, just a hundred metres from the lake. Also in 2000, Lake People was transformed into a Ltd. company.
