FiiO RC-78B Re-Cable for Balanced Earphones (various models)

Be the first to write your review

Product Code: 1662

Condition: New product

Add to wishlist

Send to a friend
Send to a friend

FiiO RC-78B Re-Cable for Balanced Earphones (various models)
Recipient :
Name of your friend ^* :
E-mail address of your friend ^* :
^* Required fields
or Cancel

Description
Designer
Comments (0)
Questions (0)

Description

FiiO RC-78B 2.5mm Silver-plated Replacement Balanced Earphone Cable for Westone UM3XRC / W4R

Description

Calling All Balanced Output Enthusiasts

Based on RC-WT1,the new RC-78B swaps the 3.5mm jack out for a 2.5mm 4-pole plug.With its separate Left/Right channel wires and separate +/- signal transfer,the RC-78B enables balanced operation for your earphones.When connected to a balanced headphone amplifier(such as the FiiO AM3),RC-78B can greatly enhance channel separation as well as markedly increase the signal to noise ratio.This results in a wider sound stage and more controlled,textured bass – perfect for balanced output enthusiasts.

A Little Extra Transparency makes for A Lot More Individuality

From the plug joint,to the Y splitter,to the earphone-side connector,the new RC-78B is wrapped with transparent polycarbonate to separate itself from the unicolor cable.Not only does this striking visual element give your earphones some character,it naturally also invites you to take a closer look with its revealing view of the insides.

Stunning Looks backed by Impressive Internals

The RC-78B adopts Teflon*FEP(fluorinated ethylene propylene) for the sheath and silver-plated copper as the conductor.11 strands of silver-plated copper wires (each with a diameter>0.08mm) make up each of the 8 separate cables,which are all woven into one audio cable with separate wires for the Left/Right channels.Both the straight 2.5mm plug and the CIEM connector (with a 0.78mm diameter) are made of gold-plated copper.These premium choices of materials ensure the RC-78B is a high quality cable that is highly elastic,tough against scrapes,and resistant to aging.

Boundless Compatibility

Westone UM3XRC / W4R / NF Audio NF2 / NF3 / NF4 / JH Audio JH13 / JH 16 / Earsonics SM64

Specification

Length: 120cm (excluding the plug)
Diameter of conductor: 26AWG (φ0.4mm)
Diameter of conductor including outer skin: φ0.6mm
Diameter of cable: φ2.5mm
Impedance of single channel for headphone cable: 0.16Ω(1.2m)
Suitable temperature: -80-200℃
High pressure resistance: 150V
Diameter of contact pin: 0.78mm

Designer

FiiO logo

About FiiO Electronics Technology Co., Ltd.

01 Brand Introduction - HiFi+Fashion

FiiO Electronics Technology Co., Ltd. was established in 2007. It is a high-tech enterprise that combines research, development, production and sales, and its sales are mainly based on its own FiiO brand as opposed to OEM/ODM. It focuses on digital audio, with current mainstay products being portable headphone amplifiers, DAC / amps and portable digital audio players.

FiiO: It is composed of Fi (Fidelity) from HiFi and iO (represents number 1 and 0) which indicates the sincerer feeling and more convenient life the digital tech has brought to us.

飞傲: The Chinese transliteration of FiiO, as well as representing youthful vigor and the active & innovative spirit of the company.

Audio products are meant to fulfill the spiritual pleasure of users.

FiiO provides products and service related to music.
We also hope to bring happiness to our users with the provided products and service, which is also the key value of FiiO.

Customer Service

Good after-sales service, more reliable
Great user experience, more pleasure
Variety of activities, more involved

About products

Affordable: FiiO products are well-known for its feature of high cost-performance. Lowering the entry level to make more customers can afford.
Easy to use: FiiO pays great attention to the user experience. We are not only provide products with high quality, but also easy to use and with long lasting durability.
More accessories bring more fun: Enable to play in a variety way and use under more possible environments.
Updates available: Equipped with a variety of ports, it makes the music players can still connect to external amp/DAC for upgraded enjoyment.
Endless transformability available: With replaceable amp module and expandable storage, the X7 can bring more playability.

02 Company Profile

Research & Development Team

Twenty years of R&D experience in audio products
Former core R&D team for audio products from OPPO
A team of 20 professional R&D engineers in software, hardware, industrial design, structure and electro-acoustic.

Research & Development Investment

FiiO keeps bringing in advanced equipments and high-tech talents so as to ensure the stable growth and long term competitive edge. Up till now, the team size has expanded three times than that of 2007 when we established.

Team Composition

The R&D team is made up of development dep, engineering dep and QC dep, with 60+engineers in total.

Authorized certifications

FC, CE, KC, CCC and ISO9001:2008 ensure the safety and quality of the products.

Production management

FiiO has strict requirements to production with almost “zero tolerance” even to small problems, which is strictly in compliance with the International Quality Management System ISO9001.

QC Equipment

a. AP audio analyzer (valued at 200,000RMB).
b. Life-span test platform against high & low temperature, swing and plug & unplug trial.
Aging test carriage towards mass production.
Aging test machine under high & low temperature.

Customer oriented

Driven by customers’ needs, we innovate constantly and response promptly to the market changes. We develop new products based on customers’ needs and compete for more market shares.

Company culture - Our Vision

Present the world a better “Made in China”.

Brand Spirit

Innovation

the earliest company that designed the minimum volume headphone amplifier. First dockable amp & DAC product. First amp specially designed for iPod/iPhone. First amp with adjustable power supply and power supplied by mobile phone battery. First multifunctional headphone amp & DAC for Android smarphone. First Hi-Res music player at a price lower than 1000RMB supporting 192K music. First Android-based Hi-res music player.

Quality

Repair Rate < 1%. Sound Quality Control system. Original components imported from TI, Wolfson, Maxim. Company-wide quality control. +20 quality engineers and inspectors. Complete testing facilities.

Service

CEO at the frontline of customer service. 100% response to enquiries. The most popular headphone amplifier brand on Head-Fi. First class website and contents in the audio industry. Interaction with and support to customers on Facebook and Microblog (twitter-like social website).

Brand Mission

FiiO designs, produces and sells high-quality products at favorable prices to those who love music and style.

Comments(0)

Be the first to write your review!

Questions

ilPierez
2017-06-28 10:00
quando arriverà la nuova versione annunciata di recente del cavo RC-78B? https://uploads.disquscdn.c...
- PlayStereo
  2017-06-28 14:16
  Arriverà entro il 15 luglio circa.
  - ilPierez
    2017-07-31 12:34
    Scrivendo direttamente a Fiio mi è stato detto che la nuova versione di questo cavo ancora non c\'è. Sarei disposto ad acquistare questo ma non sono certo della compatibilità con le audeze isine 10, allego foto dei connettori della cuffia sperando possiate aiutarmi a capire se il cavo può andare bene (so che il connettore è quello ma l\'incastro può creare problemi). Nel caso procedessi all\'ordine eventualmente il reso è gratuito?https://uploads.disquscdn.c... https://uploads.disquscdn.c...
